- Single channel constant voltage
- Meet DALI Protocol IEC62386
- Wide range of input voltage: 100 - 240v AC
- Support Touch-DIM function
- Efficiency up to 92%
- Built-in active PFC function
- Cooling by free air convection
- IP20 design
- Suitable for intelligent LED lighting
Specifications
AC Current (Max.):
2A
Frequency Range:
47 - 63Hz
Full Load Efficiency (Typ.):
92%
Input Voltage:
- 100 - 240v AC
Inrush Current:
40A (Cold start at 230v AC)
IP Rating:
- IP20
Leakage Current:
< 0.50mA
Output Current:
- 11.25A
- 6.25A
Output Voltage:
- 12v DC
- 24v DC
Power Factor:
PF>0.95/115v AC (Full Loading)
Rated Power:
- 135W
- 150W
Size:
196 x 75 x 40mm
Working Temperature:
-20°C to +50°C
UOM:
EA
